Suction

Vacuum: Water

Click on photo for larger image

Description

Model: VSW-10

Total Water Flow rate: .21gpm

Voltage:220V Single Phase

Running Amps: 6 Circuit Breaker Min: 10A

Horse Power: 1 HP

Dim:L 38 x W 25 x H 39 cm Weight 62 lbs

Max. # Users/Time: 2 users





Model: VSW-20

Total Water Flow Rate: .26gpm

Voltage:220V Single Phase

Running Amps: 9 Circuit Breaker Min: 16A

Horse Power: 2 HP

Dim:L 40 x W 35 x H 44 cm Weight: 86lbs

Max # Users/Time: 4 users



Model: VSWC-10

Total Water Flow Rate: .21gpm

Voltage:220V Single Phase

Running Amps: 6 Circuit Breaker Min: 10A

Horse Power: 1 HP

Housing: Stainless

Dim: L 33 x W45 x H 59 cm Weight: 77lbs

Max # Users/Time: 2 users



Model: VSWC-20

Total Water Flow Rate: .26gpm

Voltage:220V Single Phase

Running Amps: 9 Circuit Breaker Min:16A

Horse Power: 2 HP

Housing: Stainless

Dim: L 33 x W45 x H 59 cm Weight: 100lbs

Max # Users/Time: 4 users



Model: VSWC-202

Voltage: 220V Single Phase

Horse Power: 2+2 HP

Housing: Stainless

Dim:  L 62 x W 44 x H 62 cm

Demo of Wet suction Unit

Vacuum: Dry

Click on photo for larger image

Description

Model: VSA-1

Voltage:220V Single Phase

Horse Power:1 HP

Dim: L 36 x W 45 x H 78 cm

Model: VSA-2

Voltage: :220V Single Phase

Horse Power:½ HP

Dim:L 43 x W 56 x H 80 cm

Model: VSA-3

Voltage:220V Single Phase

Horse Power:½ HP

Dim:L 34 x W 45 x H 80 cm

Model: DS-1 Portable Mouth Spray Suction

Particles popping out from the patient’s mouth during the surgery are extremely tiny and can be inhaled by dentists. These particles may be toxic for your health.

Voltage:220V Single Phase

Horse Power:1 HP

Dim:

Main Machine: L 45 x W 45 x H 50 cm

Attachment: L 23 x W 32 x H 135 cm
